Diamond Wire machines

• Place of Origin:

   China

• Type:

  Sawing and Cutting Machinery

• Genre:

  Machinery & Equipment

• sCode:

  STPR1466814

• Place of Origin:

  Italy
• Diamond Wire machines
  VIP 910

  ELECTRONIC DIAMOND WIRE SAW
  Machine properly studied and manufactured to cut big blocks, boulders and benches, when diamond wire speed adjustment is required. An inverter device is used to control and constantly adjust the diamond wire speed from 0 to 40 m/sec., according to the type of stone. The combination with the automatic feeding system by means of “supercard” or inverter, allows a very accurate management of the cutting tool and a very smooth and precise movement of the machine on the rails. It is possible to make two parallel cuts 170 or 200 cm wide and a complete rotation of 360° to cut on any angle, by means hydraulic device. The same device allows to make horizontal cuts at ground level without the use of any auxiliary accessories.

  Main electric motor power: 50 - 60 - 75 Hp
  Starter: Star delta diretto/Star Delta or direct
  Travel motor: Motore CC 1 HP vel. varianile1/Hp variable DC motor
  Wire tension: automatic controlled by a supercard
  Main flywheel diameter: mm 800 - 1000
  Lateral movement of cutting head: 1,70 2,00 mt
  Flywheel rotation: 360°
  Linear wire speed: 40 mt/sec.
  Length of rails: 2mt, 3mt
  Dimension of the machine: L=2,23; W=1,45;H=1,40mt

  MACHINE WITH INVERTER
  Main electric motor power: 50-60 Hp
  Starter: Inverter
  Linear wire speed: 0-40 mt/sec.
